INHABIT
MODULAR TINY HOUSES
INHABIT MODULES
The Inhabit Module comes with several layout options.
"Layout" refers to the placement of walls, doors, windows etc...
Select from either of these module layouts to begin designing your ideal building. All module layouts have an array of features that can be added to their particular layout.
All modules can be connected together for larger floor plans.
MODULE OPTIONS
By selecting one or more of the following module layouts and adding any of the optional features, you can create a wide variety of buildings. From workspaces and home offices to studio flats and Airbnb units, or even houses and office blocks made up of several or dozens of units that interlock into large superstructures.
Our modules are fabricated off-site and then delivered to your location, where they are easily placed and bolted together to create permanent, long-lasting buildings that can still be moved or rearranged in the future.
With Inhabit, the possibilities are endless.
ADDITIONAL FEATURES
​
Base modules are bare shells with only standard features.
Add any of the following optional extras.
​
ADDITIONAL FEATURES:
​​
+ BATHROOM
​Cobra/ICSA Taps
​Tiled Shower Walls and Floor
Concealed Cistern
Wall hung Soft close toilet
Square mirror
Downlighters
Extractor Fan in shower
​
+ BEDROOM
​
Built-in Cupboards in the Bedroom
Queen size Murphy Bed with under-desk.
​
+ KITCHENETTE
​
Kitchen cupboards
Butler Sink
2 Plate Gas Stove
12l Gas Geyser
19kg Gas Cylinder
​
+ AUDIO, VISUAL & TECH
​
Ceiling mounted HiSense 43" 4kUHD Smart TV
Sonos One WiFi Speaker + Sonos One SL WiFi Speaker Bundle Black(2 Units)
Asus N300 Wifi Router
+ KITCHEN APPLIANCES
​
Midea 6,5l Countertop Dishwasher,
Midea 36l Microwave Convection Oven,
Defy ¾ Fridge/Freezer,
Defy Washing Machine
+ ROOFTOP ACCESS
​
Pergola
Staircase
Balustrade
+ OUTDOOR ACCESSORIES
​
Hydrofire Braai Santander
Kol Kol - Woodfired Hot tub
cladded with alien species, blue
gum decking.
Roll-up canvas blinds to patio
+ GO OFF GRID!
​
Off-Grid Solar Power: Growatt 3kW24V - PylonTech 2.55kWh 24VLithium-ion
5000l Rainwater Harvesting Storage Tank,
Pascali 0,75kW Pump,
3 stage filtration and UV Light Earth Powered
+ COMFORTS
Restonic queen sized mattress
EXAMPLE FLOOR PLANS
Wanting to go beyond 18sqm floor plans?
Add several modules together.
During the design consultation process, our team will ensure that you have selected the optimal floor plan for your build. Here are a few pre-designed floor plans:
Single Studio
from R349,000
2 Bedroom Self-Catering
from R789,000
4 Bedroom Self-Catering
from R1,340,000
Double Studio
from R589,000
2 Bedroom House
from R880,000
2 Bedroom Entertainer
from R1,260,000
TECHNICAL SPECIFICATIONS
Our qualified team of experts has spent years creating and improving the design and engineering of our modules. These modules are intelligently designed to be lightweight, efficient, strong, and durable, while also making the lightest possible footprint on the environment.
We begin by constructing a structural steel frame, which is then reinforced and supported by a light steel frame. Lightweight insulated concrete is then carefully poured into the forms. Once set, these panels are used to construct the walls and floors, creating a beautiful, lightweight, yet very strong Inhabit module.
Constructing these units off-site allows us to consistently provide the highest level of workmanship. The modules are meticulously fitted to the client's exact requirements and delivered to the site within six weeks of ordering.
.jpg)
Floors
A grid layout of structural steel angles that support insulated reinforced polystyrene concrete panels (IRPC), which then receive a screed and a floor covering of the clients choice.
Roof
The roof is made up of sandwiched fire-retardant polystyrene panels with an IBR sheeting on the top side, and powder coated white aluminium sheeting on the under side.
Dimensions
Each module has a footprint of 6m long by 3m wide, and a height of 2,7m. The modules are lightweight, allowing for units to be delivered with crane trucks, and relocated later if necessary.
Walls
140mm walls consist of 2 layers of insulated reinforced polystyrene concrete, insulation, and a light steel frame. With an outer layer of glass fibre reinforcing and a fireproof plaster.
Foundations
Rapid Root Pile foundations are used to create stable and secure foundations in any terrain, with minimal impact to the site. Concrete blocks can also be used on some sites.
Modular
Modules can be joined together to create larger units. Modules can be added, removed, or re-arranged over time, allowing for layout changes and upgrades in the future.
